12-25 Ton Excavator Buckets & Attachments

Excavators are the workhorses of modern construction, transforming daunting tasks into manageable projects with their immense power and versatility. However, the effectiveness of these machines greatly depends on the quality and suitability of their attachments. Explore our range of brand new excavator buckets and attachments for 12 to 15 ton (24,000 to 35,000 lbs) excavators and 20 to 25 ton (40,000 to 60,000 lbs) excavators.

Rhinox's Range of 12 to 25 Ton Excavator Buckets & Attachments

Rhinox's new range of excavator attachments caters to excavators weighing between 12 to 25 tons (24,000 to 60,000 lbs), addressing the diverse needs of construction professionals with precision-engineered attachments. Let's delve into the offerings:

For 12 to 15 Ton Excavators:

Digging Buckets - 18", 24", 30", 36" & 48" widths

Available in 5 different widths, the Rhinox 12 to 15 ton (24,000 to 35,000 lbs) heavy-duty digging buckets are built with a dual radius shell to reduce resistance and wear when digging. These excavator buckets also feature a HB400 cutting edge, bolt-on Esco style side cutters (Esco P/N: PDE34687) and the CAT style J300 (215) tooth systems for easy replacement when worn.

Grading Bucket - 60" width

Designed to deliver incredible levelling and finishing, Rhinox's brand new 60" grading bucket for 12 to 15 ton excavators ensure accuracy and smoothness in grading operations. These grading buckets feature multiple areas of additional wear protection to improve the resistance to wear but also feature double support ribs to maximize the structural integrity. Alongside this, they feature a HB400 cutting edge and HB400 bolt-on cutting edge to further protect the front of your bucket from wear.

Skeleton Bucket - 48" width

Featuring a robust and reinforced design, the 48" Rhinox skeleton bucket excels in sorting materials, enhancing productivity on the job site. With a similar structure to the standard excavator digging bucket from this range, this screening bucket features vertical riddling tines with a thickness of 10mm (0.39") with tine support bars to help prevent the tines from bending and buckling during use.

Land Rake - 72" width

The 72" land rake is ideal for large land clearing and ground preparation task. Featuring 10 tines of HB400, each tine has a width of 30mm (1.18"), with the space between the tines coming in at 164mm (6.45"). To maintain alignment during operation, the tines feature a solid steel bar that runs through the centre of each tine.

Rake Riddle Bucket - 72" width

Our new 72" rake riddle bucket for 12 to 15 ton excavators is ground breaking for large landscaping projects. This rake bucket features 19 narrow tines with 75mm (2.95") spaces between each tine. This allows for easy removal of overgrown plants and separating of unwanted debris in the ground, like roots or bricks. Each tine is 12mm (0.47") wide with a 15mm (0.59") HB400 tip for extra protection from wear or damage when raking.

Ripper Tooth - One size

Offering enhanced ripping capabilities, the Rhinox 12 to 15 ton ripper tooth is an essential excavator attachment for breaking through hard ground and removing large rocks and roots. The stump ripper in this size range has a 70mm (2.75") HB400 shank with 10 mm (0.39") HB400 side wrap plates and front edge protector. The 12 to 15 ton ripper tooth features a CAT Style J350 (225) tooth, which is one size up from the digging buckets in this range, as well as a tab-lock hanger construction to ensure optimal strength when tearing through the ground.

For 20 to 25 Ton Excavators:

Digging Buckets - 24", 30", 36", 48" & 60" widths

Offered in 5 widths, the Rhinox heavy-duty digging buckets, to suit 20 to 25 ton (40,000 to 60,000 lbs), are manufactured with a dual radius shell aimed at minimizing resistance and wear during excavation. These excavator buckets feature a HB400 cutting edge, along with bolt-on Esco style side cutters (Esco P/N: PDE34687) and CAT style J350 (225) tooth systems for easy replacement when needed.

Grading Bucket - 72" width

Manufactured for large levelling and finishing jobs, the Rhinox's 72" grading bucket for 20 to 25 ton (40,000 to 60,000 lbs) excavators feature multiple areas of additional wear protection to improve the resistance during operation. All 72" grading buckets also feature double support ribs inside the bucket to maximize the structural integrity, as well as a HB400 cutting edge and HB400 bolt-on cutting edge to further protect the front of your bucket from wear and extend its lifespan.

Skeleton Bucket - 60" width

With its sturdy and strengthened construction, the 60" Rhinox skeleton bucket stands out for material sorting jobs. With a similar structure to the excavator digging bucket from this range, the Rhinox 20 to 25 ton skeleton bucket features vertical riddling tines measuring 12mm (0.47") in thickness, reinforced by tine support bars to prevent bending or buckling during operation.

Land Rake - 84" width

The 84" land rake is ideal for large land clearing and ground preparation task. Featuring 11 HB400 tines, with each tine having a width of 30mm (1.18"), with the space between the tines coming in at 161mm (6.34"). The tines also feature a solid steel bar that runs through the centre of each tine to maintain alignment during operation.

Rake Riddle Bucket - 84" width

The Rhinox 84" rake riddle bucket for 20 to 25 ton excavators is ground breaking for large landscaping projects. This rake bucket features 21 narrow tines with 75mm (2.95") spaces between each tine. This allows for easy removal of overgrown plants and separating of unwanted debris in the ground, like roots or bricks. Each tine is 15mm (0.59") wide with a 20mm (0.78") HB400 tip for extra protection from wear or damage when raking.

Ripper Tooth - One size

The Rhinox 20 to 25 ton ripper tooth is an essential excavator attachment for breaking through hard ground and removing large rocks and roots. The stump ripper in this size range has a 90mm (3.54") HB400 shank with 10 mm (0.39") HB400 side wrap plates and front edge protector. The 20 to 25 ton ripper tooth features a CAT Style J460 (235) tooth, which is one size up from the digging buckets in this range, as well as a tab-lock hanger construction to ensure optimal strength when tearing through the ground.

Rhinox's Commitment to Quality

At Rhinox, we understand that the reliability and performance of our attachments are paramount to the success of your projects. That's why we go above and beyond to ensure that every product that bears the Rhinox name meets the highest standard.

Lifetime Guarantee on Welds

When you invest in a Rhinox attachment, you're investing in durability and longevity. We stand behind the quality of our products with an unbeatable promise, a lifetime guarantee on all welds. Our skilled welders meticulously weld each attachment from premium materials, resulting in products that are not only strong but also built to last. Should any weld on your Rhinox attachment fail under normal use, we'll repair or replace it free of charge, ensuring your continued satisfaction and peace of mind.

Machine Fitment Guarantee

We understand the importance of a perfect fit. That's why we offer a machine fitment guarantee on all our attachments. Our team of engineers works tirelessly to ensure that each attachment is precision-engineered to seamlessly integrate with your specific make and model of excavator. Whether you're using a 12 ton (24,000 lbs) or a 25 ton (60,000 lbs) machine, you can trust that your Rhinox attachment will fit like a glove, allowing you to maximize efficiency and productivity on the job.

In the competitive landscape of construction equipment, Rhinox's new 12 to 25 ton excavator buckets and attachments range stands out as a testament to innovation and engineering excellence. With a focus on performance, durability, and versatility, these attachments redefine the capabilities of excavators, empowering construction professionals to accomplish more in less time, with greater precision. As the industry evolves, Rhinox remains at the forefront, driving efficiency, productivity, and success on the job site.
